Descripción
Tenemos más Accesorios de Redes, si quieres ver todos los modelos pulsa aquí: Accesorios de Redes
UMAC STATIONBOX XL 5-19 MIMO 5GHz 19dBi MiMo Antenna Enclosure Made for MikroTik
Nota: La carcasa integra una antena MIMO de 19dbi a 5ghz. con 2x conectores MMCX. Cables no incluidos (recomendado mínimo 15 cm.), siendo necesario adquirir 2 por antena, con conector MMCX o UFL dependiendo de la tarjeta MiniPCI que vayamos a integrar.
Compatible con la gama de modelos de Mikrotik:
-RouterBoard 9 series
MikroTik RB911G-2HPnD*, RB912UAG-2HPnD*,RB911G-5HPnD*, RB912UAG-5HPnD*
-RouterBoard 7 series
RB711-2Hn, RB711-5Hn, RB711-5Hn-M, RB711-5Hn-U, RB711-2HnD, RB711-5HnD, RB711G-5HnD, RB711UA-2HnD, RB711UA-5HnD, RB711GA-5HnD
-RouterBoard 4 series
RB411*, RB411GL*, RB411L*, RB411AH*, RB411AR*, RB411UAHR*
 ,
Antenna Design
StationBox XL has built in dual polarization antenna. We create antennas using state of the art technology combined with experience and skills of our engineers. Antenna design is addressing customer requirements for improved gain, as well as front-to-back ratio and reduced side lobes in antenna radiation pattern.
Made For MikroTik
StationBox XL is designed for seamless integration with MikroTik RouterBoards RB911, RB711, RB411 and RB433. You can install virtually everything from integrated and compact RB911 up to powerful RB433 fully loaded with 3 wireless cards and ability to feed external antennas. Visibility of RouterBoard LEDs is also maintained.
3-Axis Positioning System
StationBox® XL comes with ultimate mounting solution directly from factory. 3-Axis positioning system allows you to adjust the position of StationBox® XL in three axis using ball hinge. By ability to set azimuth, elevation and rotation, you will unleash maximum possible transmission effectivity of wireless link.
Easy Installation
StationBox XL can be easily mounted on the pole or on the wall. Our newest generation of 3-Axis Bracket uses ball hinge with special fast locking system that can be operated with one hand, even when wearing winter gloves.
Designed in Details
StationBox XL is unique and distinct from the crowd. Revolutionary designed bracket fully integrated with CPE, RouterBoard chassis sliding inside the enclosure, or small details as LEDs or locks – these are just examples of our design approach.
Robust & Durable
StationBox® XL is built to last. We use high quality UV resistant ABS plastic. Bracket Base is made of Diecast Aluminium, all hardware is made of Stainless Steel. Mechanical structure is computer simulated and tested. Our hardest tester says: aprwoofed!
TECHNICAL DATA
Material UV stabilized and weather resistant ABS
plastic, Diecast Aluminium, Stainless Steel
Flame Rating UL 94 HB
Mounting Diameter 50-70 mm
Operating Temp. -30 to +60 °C
Wind Survival 120 Km/h
Weight 1.7 Kg / 3.75 lbs single piece incl. package
Single ece Retail Box: 34 × 27 × 10 cm
